Dual Sensor Thermal Camera With Gimbal
TS01CT gimbal camera is super light dual sensor UAV payload.
thermal LWIR
640x480 @ 60 fps
Electro-Optic 30x
1920x1080 @ 60 fps
Functions
1. Provide the IR image for detection area
2. High precision visual axis stabilization function
3. With the capability of detection and recognition for ground target
4. Support search, tracking, lock, guiding, etc working ways
5. With character overlay, custom and display functions;
6. With self - check and fault diagnosis function
7. support target postion and laser ranging
Specifications
| IR sensor | Wavelength | 8μm～14μm |
| Resolution | 640x512 |
| Focal length | 25mm/F1.0 |
| FOV | 17.4°～14° |
| Video output | HD-SDI(1080P 30Hz) |
| Distance | PEOPLE:Detection 0.7km;Recognition 0.2km VEHICLE:Detection 4.2km;Recognition 1km |
| Servo System | Rotating limits | 360º continuous Pan, Pitch: -110° ~+10 º |
| Angular accuracy: | ≤2mrad |
| Stablization accuracy | ≤100μrad(1σ)(2°/Hz,1°/Hz Swing) |
| Max.angular speed | ≥50°/s |
| Max. angular acceleration: | ≥90°/S |
| Tracking Functions | Motion speed: | 30pixel/frame |
| Target imaging contrast: | 8% |
| Target imaging pixel(Mini) | 4x3 pixels |
| Support | Anti -occlusion without loss of function |
| Interface | Communication
interface | RS422 x2(TTL optional) |
| Video output | HD-SDI x1 |
Mechanical Drawing
